Quick Reference – 1
13
Front Panel Menus - At a Glance
ADDRESS 7 Sets the GPIB Address
INTF GPIB Selects an interface (GPIB or RS232)
BAUDRATE 300 Selects baud rate (300, 600, 1200, 2400, 4800, 9600)
PARITY NONE Selects message parity (NONE, EVEN, ODD, MARK, SPACE)
FLOW NONE Selects flow control (XON-XOFF, RTS-CTS, DTR-DSR, NONE)
LANG SCPI Selects language (SCPI or COMP)
*RCL 0 Recalls instrument state
*SAV 0 Saves present instrument state
ERROR 0 Displays errors in SCPI error queue
12.000V 0.204A Measures output voltage and current
12.500V MAX Measures peak output voltage
1
1.000V MIN Measures minimum output voltage
1
12.330V HIGH Measures the high level of a voltage pulse waveform
1
0.080V LOW Measures the low level of a voltage pulse waveform
1
12.000V RMS Measures rms voltage
1
0.350A MAX Measures peak output current
1
0.050A MIN Measures minimum output current
1
0.400A HIGH Measures the high level of a current pulse waveform
1
0.012A LOW Measures the low level of a current pulse waveform
1
0.210A RMS Measures rms current
1
VOLT 20.000 Sets the output voltage
CURR 2.000 Sets the output current
OC -- -- -- -- Protection status (example shows overcurrent tripped)
*RST Places the dc source in the factory-default state
PON:STATE RST Select the power-on state command (RST or RCL0)
PROT:DLY 0.08 Sets the output protection delay in seconds
RI LATCHING Sets the remote inhibit mode (LATCHING, LIVE, or OFF)
DFI OFF Sets the discrete fault indicator state (ON or OFF)
DFI:SOUR OFF Selects the DFI source (QUES, OPER, ESB, RQS, or OFF)
PORT RIDFI Sets the output port functions (RIDFI or DIGIO)
DIGIO 7 Sets and reads the I/O port value (0 through 7)
RELAY ON Sets the output relay state (ON or OFF)
2
RELAY NORM Sets the output relay polarity (NORM or REV)
2
VOLT:PROT 22 Sets overvoltage protection level
CURR:RANG HIGH Sets current range (HIGH, LOW, or AUTO)
CURR:DET ACDC Sets current measurement detector (ACDC or DC)
1
CAL ON Accesses calibration menu (See User’s Guide).
Use and to select menu parameters. Use to exit any menu and return to metering mode.
1
Not available on Agilent 6631B - 6634B or in Compatibility mode.
2
Not available on Agilent 6631B.
Address
ô
ô
ô
ô
ô
Recall
SaveShift
ErrorShift
Meter
ô
ô
ô
ô
ô
ô
ô
ô
ô
ô
Voltage
Current
Protect
Output
ô
ô
ô
ô
ô
ô
ô
ô
ô
OV
Shift
Shift Input
ô
Cal
Shift
Meter
ËÌ
