Overview of the 7890B GC
24 Getting Started
The operating panel
The operating panel consists of the display, status lights, and keyboard.
See the Operating Manual for more information.
Display
Shows status, setpoints, current
activity, and messages.
Keyboard
Use to enter settings and program the
GC.
Status lights
LEDs indicate general status, run
state, program state, external
control, and maintenance due.
