Getting Started
81150A and 81160A Getting Started Guide 47
Programming
Example
# Reset the instrument to start from a defined, default status.
*RST
# Switch off the automatic display update to increase programming
# speed
:DISPlay OFF
# Set the output function of output 1 to pulse.
:FUNCtion1 PULSe
# Set the period to 500 ns, the pulse width to 100 ns
# Settings are programmed for output 1.
:PULSe:PERiod1 500NS
:PULSE:WIDTh1 100NS
# Set the internal trigger period to 5us
:ARM:PERiod1 5US
# Switch to triggered mode and select the internal
# trigger source
:ARM:SENSe1 EDGE
:ARM:SOURce1 INT2
# enable burst mode and set the burst length to 4
:TRIGger1:COUNt 4
# Enable the output 1 and the complement output 1.
:OUTput1 ON
:OUTput1:COMPlement ON
