Agilent Technologies 81150A User Manual

Getting Started
81150A and 81160A Getting Started Guide 19
3.1 Setting up a Clock Signal
Task
To set up a continuous clock signal with 50 MHz frequency, a duty cycle of
50%, a high Level of 2.5 V and a low level of 0.0 V.
Duty Cycle = 50%
f = 50 MHz
0.0 V
2.5 V
