To set the operating mode and trigger mode as required, do the following:
Before setting any values, press the Store/Recall key and press the
Set to Defaults softkey.
Press the Ch 1 key to select channel 1.
Press the normal and inverted output keys to enable both outputs of
channel 1.
The Continuous trigger mode is enabled by default. Therefore, we do
not change it. Now, we only need to select a Pulse waveform.
To select a Pulse waveform, simply press the Pulse key given on the
Front Panel.
By default, the Frequency is already set to 1 MHz, and the Delay to
0 seconds, therefore we do not change these values.
