Getting Started

81150A and 81160A Getting Started Guide 93

Programming

Example

# Setup Channel 2

# - Delay 200ns

# - Pulse width 10 ns

# - Lead edge 2.5 ns

# - Trailing 2.5 ns

# - Offset 0V

# - Amplitude 2Vpp

:PULSe:DELay2 200nS

:PULSe:WIDTh2 10NS

:PULSe:TRANsition2 2.5NS

:PULSe:TRANsition2:TRAiling 2.5NS

:VOLT2:OFFSet 0V

:VOLT2 2VPP

# Enable channel addition

:CHANnel:MATH PLUS

# Enable the output 1 and the complement output 1.

:OUTput1 ON

:OUTput1:COMPlement ON
