176
Chapter
3
Softke
y Menus
Menu T
rees
Figure 3-15
ACP MENU Key Menu Tree
Figure 3-16
MKR Key Menu
*
The
A
CP MENU
softkey is under the
MEAS/USER
key
. See the preceding
figure.
†
F
or firmware revisions
≤
930809.
‡
F
or firmware revisions >930809.
175
177
