74 Chapter2
Adjustment/Diagnostic Software
8. IF Bandpass Poles
8. IF Bandpass Poles
Assembly Adjusted
A5 IF assembly
Related Performance Test
Resolution Bandwidth Accuracy and Selectivity
Procedure
NOTE Use special tuning tool, part number 8710-1010.
1. Carefully follow the instructions issued by the software program.
2. After each adjustment of a component, press RECHECK POLE (on
controller) to determine the current DAC value.
