Chapter 7 351
General Troubleshooting
Block Diagram Description
Block Diagram Description
The spectrum analyzer is comprised of the six main sections listed
below. See Figure 7-6 on page 352. The following descriptions apply to
the simplified block diagram and overall block diagram located at the
end of this chapter. Assembly level block diagrams are located in
Chapters 8 through 13.
