Chapter 2 75
Adjustment/Diagnostic Software
9. IF Amplitude
9. IF Amplitude
Assembly Adjusted
A4 log amp/cal oscillator assembly A5 IF assembly
Related Performance Tests
IF Gain Uncertainty Scale Fidelity
Procedure
Figure 2-6 IF Amplitude Adjustment Setup
1. Connect equipment as shown in Figure 2-6 on page 75 and carefully
follow the instructions issued by the software program.
