524 Chapter11
Synthesizer Section
Test Connector Locations
Test Connector Locations
When troubleshooting suspected faulty circuits, use Table 11-1 on
page 525 to determine which procedure to perform.
Figure 11-1 illustrates test connector locations on the A14 and A15
assemblies.
The pin locations of a 16-pin test connector are indicated in Figure 11-2
on page 525.
Figure 11-1 A14 and A15 Assembly Test Connectors
