Agilent Technologies 8565EC

Chapter 8 379
ADC/Interface Section
Introduction
16-Bit Post-Trigger Counter ...................................... page 420
15-Bit (32 K) Circular Address Counter ................... page 420
Video Trigger Comparator ........................................ page 421
Table 8-1 W2 Control Cable Connections (1 of 2)
Signal A3J2
(pins)
A4J2
(pins)
A5J2
(pins)
A14J2
(pins)
A15J2
(pins)
D0 1* 1 50 1 1
D GND 2* 2 49 2 2
D1 3* 3 48 3 3
D2 4* 4 47 4 4
D3 5* 5 46 5 5
D4 6* 6 45 6 6
D GND 7* 7 44 7 7
D5 8* 8 43 8 8
D6 9* 9 42 9 9
D7 10* 10 41 10 10
A0 11* 11 40 11 11
D GND 12* 12 39 12 12
A1 13* — 38 13 13
A2 14* — 37 14 14
A3 15* 15 36 15 15
A4 16* — 35 16 16
D GND 17* 17 34 17 17
A5 18* — 33 18 —
A6 19* — 32 — —
A7 20* — 31 20 —
D GND 21* 21 30 21 21
LRF_STB 22* ———22
LFC_STB 23* — — 23 —
LIF_STB 24* — 27 — —
CAL OSC
TUNE
25 25* — — —
LLOG_STB 26* 26 — — —
VCMON ———27—
D GND 28* 28 23 28 28
RT PULSE 29* ————
HSCAN 30* — — 30 —
D GND 31* 31 20 31 31
RESERVED —————
OFL ERR 33 ———33*
R/T DAC3 34* ————
* Indicates signal source.
