Service Guide 10-5
8719ET/20ET/22ET Service Key Menus and Error Messages
8719ES/20ES/22ES Service Menus - Internal Diagnostics
RF Network Analyzers
Tests Menu
To access this menu, press .
(TEST [D]) accesses a menu that allows you to select or execute the
service tests. The default is set to internal test 1.
NOTE Descriptions of tests in each of the categories are given in “Test Descriptions”
on page 10-8.
The tests are divided by function into the following categories:
To access the (default) test in each category, press the test category softkey. To access the
other tests, use the numeric keypad, step keys, or front panel knob. The test number,
name, and status abbreviation will be displayed in the active entry area of the display.
Table 10-1 shows the test status terms that appear on the display, its definition, and the
equivalent GPIB code. The GPIB command to output the test status of the most recently
executed test is OUTPTESS. For more information, refer to “GPIB Service Mnemonic
Definitions” on page 10-31.
Test Category Range of Tests
Internal Tests (0–20)
External Tests (21–25)
System Verification Tests (26–42)
Adjustment Tests (43–54)
Display Tests (55–61)
Test Patterns (62–76)
Table 10-1 Test Status Terms
Test Status Terms Definition GPIB Code
PASS PASS 0
FAIL FAIL 1
-IP- IN PROGRESS 2
(NA) NOT AVAILABLE 3
-ND- NOT DONE 4
DONE DONE 5
