Module 8
Capacitance Measurement
8-9
Cgs
Conductance
Capacitance Measurement
Measurement Example
This is the measurement example of the MOS FET Cgs-Vg characteristics.
To make the measurement, set SMU1 and SMU2 to COMMON. And set the CMU as shown in the
next page.
