Agilent Technologies E3632A Service Guide

Chapter 6 Replaceable Parts
E3632-60002 Main PC Assembly
103
6
E3632-60002 Main PC Assembly
Reference
Designator
Agilent Part
Number
Qty Part Description Mfr.
Code
Mfr. Part Number
C1 0180-4228 1 CAP-FXD 47uF +-20% 10V TA 12340 T491D476M010AS
C2-6 0160-6497 42 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C7-8 0160-6225 2 CAP-FXD 0.33uF +-10% 250V POLYE-MET 06127 MKS4-.33/250/10
C9-12 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C13 0180-3751 4 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C14-15 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C16 0180-3643 1 CAP-FXD 470uF +-20% 25V AL-ELCTLT 06360
SME25VB471M10X16LL
C17-18 0160-7746 2 CAP-FXD 0.33uF +- 5% 25V CER X7R 02010 12103C334JATMA
C19 0180-4853 2 CAP-FXD 2200uF +-20% 50V AL-ELCTLT 06360 KMG1H222H
C20 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C21 0180-4854 2 CAP-FXD 2200uF +-20% 35V AL-ELCTLT 06360 KMG1V222H
C22 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C23 0180-4854 CAP-FXD 2200uF +-20% 35V AL-ELCTLT 06360 KMG1V222H
C24 0180-4853 CAP-FXD 2200uF +-20% 50V AL-ELCTLT 06360 KMG1H222H
C25-26 0180-4116 2 CAP-FXD 22uF +-20V TA 12340 T491D226M020AS
C27-29 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C30-31 0160-5947 2 CAP-FXD 1000pF +-10% 50V CER X7R 06352 C2012X7R1H102K
C32 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C33 0160-6940 2 CAP-FXD 0.33uF +-20% 50V CER Z5U 12340 C1210C334M5UAC
C34-35 0180-3751 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C36 0180-4855 3 CAP-FXD 1000uF +-20% 80V AL-ELCTLT 01542 0180-4855
C37 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C38 0160-6940 CAP-FXD 0.33uF +-20% 50V CER Z5U 12340 C1210C334M5UAC
C39 0160-5550 1 CAP-FXD 0.1 uF +-5% 100V POLYC-MET 10200 MC1-9196J
C40-43 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C44 0160-6736 4 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C45 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C46 0180-4855 CAP-FXD 1000uF +-20% 80V AL-ELCTLT 01542 0180-4855
C47 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C48 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C49 0160-5954 4 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C221J5GAC
C50 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C51 0160-5954 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C221J5GAC
C52-55 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C56 0180-3744 1 CAP-FXD 4.7uF +- 20% 10V TA 12340 T491B475M010AS
