Agilent Technologies E3632A Service Guide

Chapter 6
Replaceable Parts
E3632-60002 Main PC Assembly
104
Reference
Designator
Agilent Part
Number
Qty Part Description Mfr.
Code
Mfr. Part Number
C57-58 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C59-64 0160-5892 6 CAP-FXD 0.22uF +-10% 63V POLYE-MET 11892 MMK5224K63L6
C65 0180-4855 CAP-FXD 1000uF +-20% 80V AL-ELCTLT 01542 0180-4856
C66-67 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C68 0180-3751 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C69 0160-5944 2 CAP-FXD 0.047uF +-10% 50V CER X7R 12340 C0805C473K5RAC
C70 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C71-75 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C76 0160-7061 1 CAP-FXD 2200pF +-10% 50V CER X7R 12340 C0805C222K5RAC
C77 0160-5944 CAP-FXD 0.047uF +-10% 50V CER X7R 12340 C0805C473K5RAC
C78 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C79 0160-7711 1 CA-FXD 4700pF +-10% 50V CER X7R 12340 C0603C472K5RAC
C80 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C81 0160-5956 1 CAP-FXD 56pF +-5% 50V CER C0G 12340 C0805C560J5GAC
C82 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C83 0160-6727 1 CAP-FXD 0.033uF +-10% 50V CER X7R 09939
GRM42-6X7R333K50V
C84 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C85 0160-5954 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C221J5GAC
C86 0160-6497 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C87 0160-5954 CAP-FXD 220pF +-5% 50V CER C0G 12340 C0805C221J5GAC
C88-89 0180-3469 2 CAP-FXD 100uF +-20% 35V AL-ELCTLT 06360
KME35VB101M8X11LL
C91 0160-4065 1 CAP-FXD 0.1uF +-20% 250V PPR-MET 11892 PME271M610M
C92-93 0160-4183 2 CAP-FXD 1000pF +-20% 250V PPR-MET 11892 PME271Y410M
C94 0180-4235 1 CAP-FXD 470uF +-20% 50V AL-ELCTLT 06360
KME50VB471M12X20LL
C95 0160-4535 1 CAP-FXD 1uF +-10% 50V CER X7R 12340 C330C105K5R5CA
C96 0160-5957 1 CAP-FXD 47pF +-5% 50V CER C0G 02010 08055A470JATA
C97-99 0160-5959 3 CAP-FXD 33pF +-5% 50V CER C0G 02010 08055A330JATA
C100 0160-5967 CAP-FXD 100pF +-5% 50V CER C0G 02010 08055A100JATA
C101 0160-6497 1 CAP-FXD 0.1uF +-10% 50V CER X7R 12340 C1206C104K5RAC
C102 0160-3237 1 CAP-FXD 0.1uF +-20% 50V CER Z5U 01542 RPE132Z5U104M50
CR1-2 1906-0291 10 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR3-4 1906-0407 3 DIODE-FW BRDG 400V 1A 04504 DF04S
CR5 1902-0579 3 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR6 1902-0651 1 DIODE-ZNR 9.1V 5% PD=1W IR=10UA 01542 1902-0651
CR7 1906-0407 DIODE-FW BRDG 400V 1A 04504 DF04S
CR8 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236 (SOT-23) 06337 BZX84C6V2
CR9-10 1902-1570 2 DIODE-ZNR 2.4V 5% TO-236 (SOT-23) 03334 BZX84-C2U4
CR11 1906-0400 1 DIODE-FW BRDG 600V 6A 04504 GBU8J
