32 Chapter 2
Front and Rear Panel Features
Rear-Panel Features
Table 2-2 and Table 2-3. show the appropriate rear panel slots to be used for the optional cards
available with the Agilent ESA Spectrum Analyzers. Refer to Table 2-2. if you have an Agilent
ESA-L Series Spectrum Analyzer. Refer to Table 2-3. if you have an Agilent ESA-E Series Spectrum
Analyzer.
(P) = Preferred Card Slot
(A) = Acceptable Card Slot
(–) = Unacceptable Card Slot
Table 2-2 Agilent ESA-L Series (E4403B, E4408B, E4411B)
Slot # 1256
GPIB and Parallel (Option A4H) P A – –
Serial and Parallel Interface (Option 1AX) P A – –
IF, Video, and Sweep Ports (Option A4J) – – P –
Frequency Extension
a
a. The Frequency Extension Assembly comes standard with the Agilent E4408B.
––P
Table 2-3 Agilent ESA-E Series (E4401B, E4402B, E4404B, E4405B, E4407B)
Slot #
1
a
a. Some cards may not be installed due to mechanical interference.
23456
GPIB and Parallel Interface (Option A4H)
b
b. Only one optional remote interface (Option A4H or Option 1AX) can be installed at a time.
PAAA– –
RS-232 and Parallel Interface (Option 1AX)b P A A A – –
Fast Time Domain Sweeps (Option AYX)
c
c. Only one IF and Sweep Port option (Option A4J or Option AYX) can be installed at a time.
–APA––
IF, Video, and Sweep Ports (Option A4J)c A A A A P A
FM Demodulation (Option BAA)
d
d. Only one demod option (Option BAA or Option 106) can be installed at a time.
– AP AAA
Noise Figure (Option 219) A A P A – –
Frequency Extension
e
– AAAAP
Digital Signal Procession and Fast ADC
(Option B7D)
–––P––
RF Communications Hardware (Option B7E) – – – – P –
ACPR Dynamic Range Extension (Option 120) – P AAAA
Bluetooth
f
FM Demodulation (Option 106)d
,g
– AP AAA
To Next Page
