1. Special rugged female connector specifi cally for connecting to the network analyzer test port, but does not mate with a standard male connector.
2. 1250-1744 3.5 mm (f) to 50 ohm Type-N (m) adapters are recommended to connect to the E5071C Option x4x, and x8x test ports, which have Type-N (f)
connectors.
3. NMD-3.5 mm (f) to 3.5 mm (f), or 3.5 mm (f) to 3.5 mm (f) adapters are recommended to connect to the E5071C Option xK5, which have NMD-3.5 mm (m)
connectors.
N4433A-xxx mixed-connector options:
Connector
type
Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
□
N4691B Microwave ECal: 300 kHz to 26.5 GHz, 2 ports.
Includes:
Option M0F module with:
N4691-60001 3.5 mm (f) to 3.5 mm (m) ECal module
Option 00M module with:
N4691-60002 3.5 mm (m) to 3.5 mm (m) ECal module
Option 00F module with:
N4691-60003 3.5 mm (f) to 3.5 mm (f) ECal module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Cables
□
11500E
2, 3
cable, APC 3.5 mm (m), DC to 26.5 GHz
Includes: one 610 mm (24 in) with male connectors.
□
11500F
2, 3
150 cm cable, APC 3.5 mm (m), DC to 26.5 GHz
Includes: one 1520 mm (60 in) with male connectors.
□
85131C
1
single, semi-rigid: 3.5 mm (f) to PSC-3.5 mm (f),
81 cm, 32 inches
□
85131D
1
set, semi-rigid:
85131-60009 one 3.5 mm (f) to 3.5 mm (m), 53 cm,
21 inches,
85131-60010 one 3.5 mm (f) to PSC-3.5 mm (f), 53 cm,
21 inches
□
85131E
1
single, fl exible: 3.5 mm (f) to PSC-3.5 mm (f),
96.5 cm, 38 inches
□
85131F
1
set, fl exible:
85131-60012 one 3.5 mm (f) to 3.5 mm (m), 62.2 cm,
24.5 inches
85131-60013 one 3.5 mm (f) to PSC-3.5 mm (f), 62.2 cm,
24.5 inches
□
85131G
1
single, semi-rigid: 3.5 mm (f) to 3.5 mm (m),
53 cm, 21 inches
□
85131H
1
single, fl exible: 3.5 mm (f) to 3.5 mm (m),
62.2 cm, 24.5 inches
□
85134C
1
single, semi-rigid: PSC-3.5 mm (f) to 2.4 mm (f),
81 cm, 32 inches
□
85134D
1
set, semi-rigid:
85134-60002 one 2.4 mm (f) to PSC-3.5 mm (f), 53 cm,
21 inches
85134-60001 one 2.4 mm (f) to PSC-3.5 mm (m), 53 cm,
21 inches
□
85134E
1
single, fl exible: PSC-3.5 mm (f) to 2.4 mm (f),
96 cm, 38 inches
□
85134F
1
set, fl exible:
85134-60004 one 2.4 mm (f) to PSC-3.5 mm (f), 61 cm,
24 inches
85134-60003 one 2.4 mm (f) to PSC-3.5 mm (m), 61 cm,
24 inches
□
85134G
1
single, semi-rigid: 2.4 mm (f) to PSC-3.5 mm (m),
53 cm, 21 inches
□
85134H
1
single, fl exible: 2.4 mm (f) to PSC-3.5 mm (m),
61 cm, 24 inches
□
N4419A-B20 set of 4, fl exible: 3.5 mm (m) to 3.5 mm (f),
91.4 cm, 36 inches
□
Z5623A-B20 set of 4, fl exible: 3.5 mm (m) to 3.5 mm (m),
91.4 cm, 36 inches (phase-matched)
Adapters
□
11853A 50 ohm Type-N accessory kit.
Includes:
1250-1472 Type-N (f) to Type-N (f) adapter (two included)
1250-1475 Type-N (m) to Type-N (m) adapter (two included)
85032-60009 Type-N (f) short
85032-60008 Type-N (m) short
□
11878A Type-N to 3.5 mm adapter kit.
Includes:
1250-1744 3.5 mm (f) to 50 ohm Type-N (m) adapter
1250-1743 3.5 mm (m) to 50 ohm Type-N (m) adapter
1250-1745 3.5 mm (f) to 50 ohm Type-N (f) adapter
1250-1750 3.5 mm (m) to 50 ohm Type-N (f) adapter
□
11524A 7 mm to Type-N (f) adapter
□
11525A 7 mm to Type-N (m) adapter
□
85130C
1
3.5 mm to Type-N
□
85130D
1
3.5 mm to 3.5 mm
Includes:
85130-60005 NMD-3.5 mm to PSC-3.5 mm (f)
85130-60006 NMD-3.5 mm to PSC-3.5 mm (m)
□
85130F
1
2.4 mm to 3.5 mm
