7
1. A sliding load is not supported by the ENA.
2. An offset load is not supported by the ENA.
Measurement Accessories
A complete list of RF and microwave test accessories
is available on our Web site:
www.agilent.com/fi nd/accessories
Accessories are available with the following connector
types: 50 ohm Type-N, 3.5 mm, 7 mm, 2.4 mm, 2.92 mm,
1.85 mm, 1.0 mm and waveguide.
Test port cables and a calibration kit/ECal module should
be added for a complete measurement system.
Calibration kits
Coaxial measurements
Mechanical calibration kits include standards, such
as opens, shorts and loads, which are measured by the
network analyzer for increased measurement accuracy.
Electronic calibration (ECal) kits replace mechanical cali-
bration standards with one solid-state calibration module
that is controlled by the network analyzer via USB. ECal kits
provide many different impedances to the test ports which
enables a full two-port calibration to be performed quickly
with a single connection. This technique reduces operator
errors and connector wear and abrasion.
Choose a calibration kit for each connector type to be used.
Economy, includes:
• open standards (male and female)
• short standards (male and female)
• fi xed-termination standards (male and female)
Standard, includes the devices in the economy kit and adds:
• sliding load standards
1
(male and female) or a series of
offset shorts
Precision, includes the devices in the economy kit and adds:
• 50 ohm airline(s) for TRL calibration
• TRL adapters
Waveguide measurements
For waveguide measurements, Agilent offers mechanical
calibration kits that include:
• waveguide-to-coax adapters (X, P, K, R, Q, U, and V bands)
• precision waveguide section
• fl ush short circuit
• fi xed terminations
2
• straight section
Cables and adapter sets
Agilent offers the following types of cables:
• single cables: semi-rigid or fl exible
• cable sets: semi-rigid or fl exible
There are also adapter sets that protect the test port
and convert the port to the desired connector interface.
These kits contain:
• one male adapter
• one female adapter
To attain the best mechanical rigidity for device connection,
use a single cable and the appropriate special adapter set.
To attain the greatest fl exibility for device connection, use
a cable set.
