1. Minimum frequency changes from 9 kHz to 100 kHz.
2. Bias tees are removed.
3. E5071C-017 is required to use E5071CU-018.
Upgrade kits
Upgrade kits for the E5071C
Protecting your hardware investment
The E5071C ENA network analyzer is a safe investment
because of its fl exibility. Easily upgrade any ENA software
or hardware feature whenever you need that feature.
Software option upgrades (Customer installable)
a) Add Frequency-offset mode option:
Order the E5003A with E5003A-1FP
Frequency-offset mode for the E5071C.
b) Add Time-domain analysis option:
Order the E5004A with E5004A-1FP Time domain
analysis for E5071C.
c) Add Measurement Wizard Assistant software:
Order the E5005A with E5005A-1FP Measurement
wizard assistant software for the E5071C.
Hardware option upgrades
(Installed by the Agilent service center)
Please refer to “E5071C Test set option table” below and
the “E5071C Hardware upgrade option matrix” on page
14 of this document for help selecting the proper upgrade
options.
E5071C Upgrade option list
a) Maximum frequency upgrade
E5071CU-280 from 4.5 GHz to 8.5 GHz for E5071C-240
E5071CU-285 from 4.5 GHz to 8.5 GHz for E5071C-245
E5071CU-480 from 4.5 GHz to 8.5 GHz for E5071C-440
E5071CU-485 from 4.5 GHz to 8.5 GHz for E5071C-445
E5071CU-2K5 from 8.5 GHz to 20 GHz for E5071C-280/285
E5071CU-4K5 from 8.5 GHz to 20 GHz for E5071C-480/485
b) Add bias tees
1
E5071CU-100 Add bias tees for E5071C-240
E5071CU-101 Add bias tees for E5071C-280
E5071CU-102 Add bias tees for E5071C-440
E5071CU-103 Add bias tees for E5071C-480
c) Lower frequency limit upgrade
2
E5071CU-200 Lower limit upgrade from 100 kHz to
9 k Hz for E5071C-245
E5071CU-201 Lower limit upgrade from 100 kHz to
9 k Hz for E5071C-285
E5071CU-202 Lower limit upgrade from 100 kHz to
9 k Hz for E5071C-445
E5071CU-203 Lower limit upgrade from 100 kHz to
9 k Hz for E5071C-485
d) Measurement port upgrade
E5071CU-300 Port up from 2 ports to 4 ports for E5071C-240
E5071CU-301 Port up from 2 ports to 4 ports for E5071C-245
E5071CU-302 Port up from 2 ports to 4 ports for E5071C-280
E5071CU-303 Port up from 2 ports to 4 ports for E5071C-285
E5071CU-304 Port up from 2 ports to 4 ports for E5071C-2K5
e) Add high stability time base option
E5071CU-1E5 Add high stability time base
f) Add removable hard disk drive feature
E5071CU-017 Upgrade to removable hard disk drive
E5071CU-018
3
Hard disk drive kit (spare hard disk,
customer installable)
E5071C Test set option table
Frequency range & bias tees
Number of test ports
2-port 4-port
9 kHz to 4.5 GHz without bias tees 240 440
100 kHz to 4.5 GHz with bias tees 245 445
9 kHz to 8.5 GHz without bias tees 280 480
100 kHz to 8.5 GHz with bias tees 285 485
300 kHz to 20 GHz with bias tees 2K5 4K5
• When upgrading the maximum frequency, number of ports, bias-tees
or lower frequency limit, please be aware that the upgrade options
listed in the “E5071C Hardware upgrade option matrix” need to be
ordered as well (e.g. To upgrade the unit from Opt. 240 to Opt. 480,
order “E5071CU-300” and “E5071CU-480” respectively).
• “Add high stability time base” and “Upgrade to removable HDD” can
be ordered at the same time as the upgrade options for frequency,
number of ports, bias-tees or lower frequency limit.
