12
1. For this option order K281C-012.
For devices with 75 ohm Type-N connectors
Mechanical calibration kits
□
85036B DC to 3 GHz, includes:
00909-60019 75 ohm Type-N (m) broadband load
00909-60020 75 ohm Type-N (f) broadband load
85036-60012 75 ohm Type-N (m) short
85036-60011 75 ohm Type-N (f) short
85032-60007 75 ohm Type-N (m) open
85032-20001 75 ohm Type-N (f) open body
85036-60010 75 ohm Type-N (f) open center conductor
extender
85036-60013 75 ohm Type-N (m) to (m) adapter
85036-60014 75 ohm Type-N (f) to (f) adapter
85036-60015 75 ohm Type-N (m) to (f) adapter
□
85036E DC to 3 GHz, includes:
00909-60019 75 ohm Type-N (m) broadband load
85036-60016 75 ohm Type N (m) combined open/short
Adapters
□
11852B Minimum-loss pad
Option 11852B-004 Type-N connectors, 50 ohm (m)
to 75 ohm (f)
Calibration must be done with a 75 ohm calibration kit
using an 11852B minimum-loss pad, and impedance
conversion to 75 ohm using the ENA’s fi xture simulator
function is required.
For devices with waveguide
Mechanical calibration kits
X Band
□
X11644A standard, WR-90: 8.2 to 12.4 GHz.
Includes:
00896-60008 X-band standard section
00910-60003 X-band termination
11644-20018 X-band short
11644-20021 X-band shim
□
85132F cable set (set of 2, fl exible 7 mm to 3.5 mm,
62.9 cm each, 24.75 inches each)
□
85135F cable set (set of 2 , fl exible,
7 mm to 2.4 mm, 53 cm each, 21 inches each)
□
X281C adapter (included in calibration kit):
WR-90 to 7 mm
P Band
□
P11644A standard, WR-62: 12.4 to 18 GHz.
Includes:
00896-60007 P-band standard section
00910-60002 P-band termination
11644-20017 P-band short
11644-20020 P-band shim
□
85132F cable set (set of 2, fl exible, 7 mm to 3.5 mm,
62.9 cm each, 24.75 inches each)
□
85135F cable set (set of 2, fl exible, 7 mm to 2.4 mm,
53 cm each, 21 inches each)
□
P281C adapter (included in calibration kit):
WR-62 to 7 mm
K Band
□
K11644A standard, WR-42: 18 to 26.5 GHz.
Includes:
00896-60006 K-band standard section
00910-60001 K-band termination
11644-20016 K-band short
11644-20019 K-band shim
□
85134F cable set (set of 2, fl exible, 3.5 mm to 2.4 mm,
53 cm each, 21 inches each)
□
K281C adapter (included in calibration kit):
WR-42 to 3.5 mm (f)
Option 012
1
WR-42 to 3.5 mm (m)
