2
1. Order the 82357B USB/GPIB interface at the same time if you want
to control power meters with the E5071C. This will allow you to
conduct scalar mixer calibrations (SMC), power calibrations, or
receiver calibrations after power calibrations.
E5071C ENA Network Analyzer
The ENA is an integrated network analyzer with a two- or
four-port S-parameter test set, a synthesized RF source, a
10.4-inch color LCD, and a hard disk drive. A 1-year return-
to-Agilent service warranty is included with the each ENA
Series network analyzer.
Step 1: Select frequency range, number of test ports,
and with or without bias tees
Up to 4.5 GHz range
9 kHz to 4.5 GHz (without bias tees)
E5071C-240 2-port S-parameter test set
E5071C-440 4-port S-parameter test set
100 kHz to 4.5 GHz (with bias tees)
E5071C-245 2-port S-parameter test set
E5071C-445 4-port S-parameter test set
Up to 8.5 GHz range
9 kHz to 8.5 GHz (without bias tees)
E5071C-280 2-port S-parameter test set
E5071C-480 4-port S-parameter test set
100 kHz to 8.5 GHz (with bias tees)
E5071C-285 2-port S-parameter test set
E5071C-485 4-port S-parameter test set
Up to 20 GHz range
300 kHz to 20 GHz (with bias tees)
E5071C-2K5 2-port S-parameter test set
E5071C-4K5 4-port S-parameter test set
Step 2: Select time base
E5071C-1E5 High stability time base
E5071C-UNQ Standard stability time base
Step 3: Select hard disk drive
E5071C-017 Removable hard disk drive
E5071C-019 Standard hard disk drive
Step 4: Choose additional options (Optional)
E5071C-008
1
Frequency offset mode
E5071C-010 Time-domain analysis
E5071C-790 Measurement Wizard Assistant software
Step 5: Choose accessories (Optional)
E5071C-1CM Rack mount kit,
E5071C-1CN Front handle kit
E5071C-1CP Rack mount and front handle kit
E5071C-810 Adds a keyboard
E5071C-820 Adds a mouse
Step 6: Choose certification documentation (Optional)
E5071C-1A7 ISO 17025 compliant calibration
E5071C-A6J ANSI Z540 compliant calibration
Step 7: Choose your warranty service (Optional)
3 year return-to Agilent warranty and service
5 year return-to Agilent warranty and service
Documentation
The documentation for the E5071C is located in the
Online Help system for the E5071C ENA network analyzer.
The ENA Service Guide and Online Help system are also
available on the Web site:
www.agilent.com/fi nd/ena
Additional product information
For additional product information, refer to the ENA
brochure available on the Web site:
www.agilent.com/fi nd/ena
