For devices with 50 ohm Type-N connectors
Mechanical calibration kits
□
85032F economy: DC to 9 GHz. Includes:
85032-60017 Type-N (m) fi xed load
85032-60018 Type-N (f) fi xed load
85032-60013 Type-N (m) open
85032-60014 Type-N (f) open
85032-60016 Type-N (m) short
85032-60015 Type-N (f) short
□
Option 85032F-100 adds:
85032-60021 Type-N (f) to Type-N (f) adapter
□
Option 85032F-200 adds:
85032-60019 Type-N (m) to Type-N (m) adapter
□
Option 85032F-300 adds:
85032-60020 Type-N (m) to Type-N (f) adapter
□
Option 85032F-500 adds:
85054-60001 Type-N (f) to 7 mm adapter (two included)
85054-60009 Type-N (m) to 7 mm adapter (two included)
□
85054D economy: DC to 18 GHz. Includes:
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7 mm adapter
85054-60032 Type-N (m) to 7 mm adapter
85054-60037Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-60046 Type-N (m) fi xed load
85054-60047 Type-N (f) fi xed load
Electronic calibration kits
□
85092C RF ECal: 300 kHz to 9 GHz, 2 ports
Includes:
Option 85092C-MOF module with:
85092-60008 Type-N (f) to Type-N (m) RF ECal module
Option Option 85092C-00M module with:
85092-60009 Type-N (m) to Type-N (m) RF ECal module
Option 85092C-00F module with:
85092-60010 Type-N (f) to Type-N (f) RF ECal module
Option 85092C-00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
□
N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4 ports
Includes:
Option 020 module with:
N4431-60007 4 x Type-N (f) ECal module
N4431B-xxx mixed-connector options:
Connector type
Port A
option
Port B
option
Port C
option
Port D
Option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
7-16 (f) 105 205 305 405
7-16 (m) 106 206 306 406
