Agilent Technologies E5071C Configuration Guide

9
□
N4432A Microwave ECal: 300 kHz to 18 GHz, 4 ports
Includes:
Option 020 module with:
N4432-60003 4 x Type-N (f) ECal module
N4432A-xxx mixed-connector options:
Connector type
Port A
option
Port B
option
Port C
option
Port D
Option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
□
N4690B Microwave ECal: 300 kHz to 18 GHz, 2 ports
Includes:
Option M0F module with:
N4690-60001 Type-N (f) to Type-N (m) ECal module
Option 00M module with:
N4690-60002 Type-N (m) to Type-N (m) ECal module
Option 00F module with:
N4690-60003 Type-N (f) to Type-N (f) ECal module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
Cables
□
N6314A 50 ohm Type-N RF cable, DC to 12.4 GHz
includes 8120-8862 one 610 mm (24 in) cable with male
connectors
□
N6315A 50 ohm Type-N RF cable, DC to 12.4 GHz
includes 8121-0027 one 610 mm (24 in) cable with both
female and male connectors
Adapters
□
11853A 50 ohm Type-N accessory kit. Includes:
1250-1472 Type-N (f) to Type-N (f) adapter (two included)
1250-1475 Type-N (m) to Type-N (m) adapter (two included)
11511A Type-N (f) short
11512A Type-N (m) short
□
11878A Type-N to 3.5 mm adapter kit. Includes:
1250-1744 3.5 mm (f) to 50 ohm Type-N (m) adapter
1250-1743 3.5 mm (m) to 50 ohm Type-N (m) adapter
1250-1745 3.5 mm (f) to 50 ohm Type-N (f) adapter
1250-1750 3.5 mm (m) to 50 ohm Type-N (f) adapter
□
11524A 7 mm to Type-N (f) adapter
□
11525A 7 mm to Type-N (m) adapter
