114 Chapter 2
Front-Panel Key Reference
Input/Output
CAUTION When operating in dc coupled mode, ensure protection of the input
mixer by limiting the input level to 0 Vdc, +30 dBm.
CAUTION To prevent damage to the EMC analyzer from power line switching
transients:
— Disconnect the receiver input from the LISN (or current clamp)
output prior to connecting or disconnecting the mains to the EUT.
— Disconnect the receiver input from the LISN (or current clamp)
output prior to turning the EUT on or off.
— If you are using a switchable LISN, disconnect the receiver input
from the LISN output prior to switching the LISN between lines.
— Disconnect the receiver input from the current clamp output prior to
attaching or detaching it to a powered EUT main.
Key Access:
Input/Output
Amptd Ref
(f=50 MHz)
On Off
Agilent E7401A only. Turns the internal amplitude reference signal on
or off. When the internal amplitude reference signal is on, the RF input
is disabled.
Key Access:
Input/Output
Amptd Ref Out
(f=50 MHz)
On Off
Agilent E7402A, E7403A, E7404A, and E7405A only. Turns the
external amplitude reference signal on or off.
Key Access:
