Chapter 2 165
Front-Panel Key Reference
Peak Search
Peak Search
Places a marker on the highest peak based on the setting of the search
parameters, Max (default) or Param. Refer to Peak Search Type on
page 168, for more information on the effect of setting
Peak Search to
Max or Param. When you preset the analyzer, the Peak Search is set to
Max unless you save Peak Search (Param) as part of the user preset
conditions and set
Preset to User. Refer to Preset on page 170, for more
information on presetting the analyzer.
NOTE All peak search functions ignore the LO feedthrough. Peak Search may
locate the LO feedthrough when
FREQUENCY, Scale Type (Log) is
selected.
Meas Tools Accesses the following frequently used menu keys which are replicated
here for your convenience.
Peak Search Performs peak search as described above.
Key access:
Peak Search, Meas Tools
Next Pk Right
Refer to “Next Pk Right” on page 166.
Key access:
Peak Search, Meas Tools
Next Pk Left Refer to “Next Pk Left” on page 166 of this chapter.
Key access:
Peak Search, Meas Tools
Delta
Refer to “Delta” on page 115.
Key access:
Peak Search, Meas Tools
Mkr → CF Refer to “Mkr → CF” on page 116.
Key access:
Peak Search, Meas Tools
Mkr → Ref Lvl
Refer to “Mkr → Ref Lvl” on page 117.
Key access:
Peak Search, Meas Tools
Function
Refer to “Function” on page 118.
Key Access:
Peak Search, Meas Tools
Band Power
Refer to “Band Power” on page 118.
Key Access:
Peak Search, Meas Tools,
Function
Marker Noise
Refer to “Marker Noise” on page 118.
Key Access:
Peak Search, Meas Tools,
Function
