Chapter 2 133
Front-Panel Key Reference
Meas Setup
Apply Corrections
Yes No
Pressing Apply Corrections (Yes) turns on the
amplitude-correction factors. Corrections will only be
applied to the sets of correction factors whose correction
state is set to On. To turn a set of correction factors on,
use the
Correction On Off key in the Antenna, Cable,
Other, or User menus. When
Apply Corrections (Yes) is
selected, an A will appear on the screen annotation
whether or not a correction set has been turned on
using the
Correction (On) key in the Antenna, Cable,
Other, or User menus.
Key Access:
Meas Setup, More, Corrections
Antenna
Accesses the Antenna menu of keys which allow you to
correct for antenna loss, but may be used for any kind
of correction.
Key Access:
Meas Setup, More, Corrections
Correction On Off
Turns the amplitude correction
function on or off for the selected set.
The corrections state must be set to On
for the correction to be applied.
Key Access:
Meas Setup, More,
Corrections, Antenna
NOTE Antenna, Cable, and Other correction factors are generally entered as
positive values. This indicates a loss in the external device. User
correction factors are typically entered as negative values which
indicate a gain in the external device.
Antenna Units Accesses the antenna measurement
units menu. You can choose pTesla,
Gauss, µV/m, µA/m or No Conversion as a
measurement unit. Antenna Units is
active only when Antenna is chosen
from the Select list, otherwise it is
grayed out.
Key Access:
Meas Setup, More,
Corrections, Antenna
Edit
Accesses menu keys that allow you to
create and edit an amplitude-correction
factor set. It puts the analyzer into a
split-screen mode where the correction
data is displayed in a table under the
trace data. Pressing
ESC while in this
menu will exit the menu and remove
