152 Chapter 2
Front-Panel Key Reference
MEASURE
NOTE The Peak ∆ LL1 and Peak ∆ LL2 values are displayed in the signal list
if the appropriate limit line is turned on and Limit Test has been turned
On.
QP Ampl Pressing this key will enable the
quasi-peak delta values for display in
the signal list.
Key Access:
MEASURE, More, Signal List,
List Edit
NOTE The Quasi-Peak ∆ LL1 and Quasi-Peak ∆ LL2 values are displayed in
the signal list if the appropriate limit line is turned on and Limit Test
has been turned On.
AV Ampl Pressing this key will enable the
average delta values for display in the
signal list.
NOTE The Average ∆ LL1 and Average ∆ LL2 values are displayed in the
signal list if the appropriate limit line is turned on and Limit Test has
been turned On.
Key Access:
MEASURE, More, Signal List,
List Edit
Comment
Selects the comment data to be
displayed for each signal list element.
Note that when you select this key, it
will turn off other delta limit line
selections in this menu.
Key Access:
MEASURE, More, Signal List,
List Edit
Sort Signals
Accesses a list of sort options. You can define how you
want the signal list to be displayed and determine if
you want the list in ascending (Asc) or descending (Dsc)
order. These options include:
By Freq, By Pk Ampl,
By QP Ampl, By AV Ampl, By ∆ LL1, and By ∆ LL2. The
current sort order is underlined. Pressing the key again
changes the sort order. The signal list display is
refreshed when a new sort order is indicated.
Key Access:
MEASURE, More, Signal List
Signal List
On Off
Switches between signal list display
(split screen) and normal analyzer
display. The upper portion of the split
