Chapter 2 171
Front-Panel Key Reference
Preset
• If User Preset is pressed, the user preset state is recalled. To set the
user preset state, change the analyzer settings as desired, then press
System, Power On/Preset, Save User Preset.
• If
Mode Preset is pressed, the current mode settings are reset to the
factory defaults. Pressing
Mode Preset does not change the mode.
• If
Factory Preset is pressed, a factory preset will be performed as
described above.
NOTE Recalling any state, including the user preset state, will affect the
conditions of more parameters than are affected by a factory preset. For
example, external preamp gain and input impedance correction are not
affected by a factory preset but may be affected by a user preset.
NOTE In the System menu, if Power On is set to Preset, and Preset Type is set to
Factory, turning on the analyzer performs a factory preset. The last
state of the analyzer (before it was turned off) is recalled if Power On is
set to
Last. The user preset state is recalled if Power On is set to Preset
and Preset Type is set to User.
Table 2-3 Factory Preset Conditions
Amplitude correction factors off
Amplitude units dBµV log
Annotation and graticule
display
on
Attenuation 10 dB (auto-coupled)
Center frequency: 600 MHz
CF step size 10% of span
Coupled functions all set to AUTO
Detector Peak (auto-coupled)
Display line level –25 dBm, display off
Frequency (scale type) Linear
Frequency offset 0 Hz
Input Coupling
1
E7402A & E7405A with
Option UKB, E7403A and
E7404A
AC
Int Preamp off
Limit line testing off
