Chapter 2 201
Front-Panel Key Reference
System (Local)
Front Panel
Test
Allows you to verify the functionality of each
front-panel key (except
Preset). The number next to
each key name increments once each time the key is
pressed. Rotating the knobs causes the number of
pulses to be counted. Press
ESC to exit.
Key Access:
System, More, Diagnostics
Restore Sys
Defaults
Resets the “persistent” state variables to their defaults. These are
values, such as the GPIB address, that are unaffected by a power cycle
or a preset (when
Preset Type is set to Factory.)
Key Access:
System, More
Table 2-4 System Default Settings
Feature Default Setting
Color Printing On
Custom Printer, Color Capability No
Custom Printer, Language PCL3
Date Format MDY
Display Viewing Angle 4
External Amplifier Gain 0 dBm
GPIB Address 18
Input Impedance 50 (Ohm)
Instrument Color Palette Default palette
Manual Tracking Adjustment 2048
Page Size Letter
Power On Last/Preset Preset
Preset Factory/User Mode
Print Format Print screen mode
Print Orientation Portrait
Printer Selection Auto
Prints/ Page 1
RS-232 Baud Rate 9600
RS-232 DTR Control On (hardware pacing)
RS-232 Receive Pacing None (data pacing)
RS-232 RTS Control IBFULL (hardware pacing)
