94 Chapter 2
Front-Panel Key Reference
File
Key Access: File, Catalog, Type, More
Signal List
Displays all signal list files (.LST) in
the selected directory. The signal list
files contains a list of signals which
include the frequency and measured
amplitudes for each signal.
Key Access:
File, Catalog, Type, More
Report
Displays all report files in the selected
directory. Report files are saved in a
(.HTM) file type format. The Report
files can contain the screen in GIF
format, the signal list, and the analyzer
setup. The report files contain a
hyperlink to the GIF file of the analyzer
screen.
Key Access:
File, Catalog, Type, More
Sort
Accesses the Sort menu keys that allow you to sort your
files according to a selected file attribute.The selections
include,
By Date, By Name, By Extension, By Size, and
Order Up Down. Order (Up) allows you to sort files in
ascending order (for instance, A,B,C). Order (Down)
allows you to sort files in descending order (for
instance, C,B,A).
Key Access:
File, Catalog
Dir Up
Allows you to move up one directory level. If at the top
level,
Dir Up moves to the drive level, displaying the
available disk drives.
Key Access:
File, Catalog
Dir Select
Accesses the highlighted directory on your display.
Key Access:
File, Catalog
Save
Accesses menu keys that allow you to save analyzer setups, states,
traces, limits, corrections and screen data to a floppy (A:) drive or
internal flash (C:) drive.
NOTE If you intend to save trace files for use with a personal computer, save
them as .CSV (comma separated values). However, files formatted in
this way cannot be loaded back into the analyzer.
NOTE Never remove the floppy disk during a save operation. To do so could
corrupt all data on the floppy disk.
Key Access:
File
