112 1200 Series Quarternary Pump User Manual
8 Parts and Materials for Maintenance
Pump Head Assembly with Seal Wash Option
Pump Head Assembly with Seal Wash Option
Tab le 15 Pump Head Assembly with Seal Wash Option
Item Description Part Number
Complete assembly, including parts marked with * G1311-60005
1* Sapphire plunger 5063-6586
2* Plunger housing (including spring) G1311-60002
3* Support ring, seal wash 5062-2465
4* Secondary seal 0905-1175
5* Wash tube (1.0 m) 0890-1764
6* Gasket, seal wash (pack of 6) 5062-2484
7* Seal keeper 5001-3743
8* Seal (pack of 2) or
Seal (pack of 2), for normal phase applications
5063-6589
0905-1420
9* Pump chamber housing G1311-25200
10 Active inlet valve body G1312-60025
Replacement cartridge for active inlet valve (400 bar) 5062-8562
11 Outlet ball valve (complete with cartridge) G1311-60012
12* Screw lock 5042-1303
13 Purge valve G1311-60009
14* Screw M5, 60 mm lg 0515-2118
15* Seal wash pump assembly 5065-9953
Seal wash upgrade kit (see “Seal Wash Option Kit
G1311-68711” on page 118)
01018-68722
