114 1200 Series Quarternary Pump User Manual
8 Parts and Materials for Maintenance
Outlet Ball Valve Assembly
Outlet Ball Valve Assembly
Figure 28 Outlet Ball Valve Assembly
Tab le 16 Outlet Ball Valve Assembly
Item Description Part Number
Outlet ball valve — complete assembly G1311-60012
1 Socket cap 5042-1345
2 Outlet valve housing screw 01018-22410
3 Gold seal, outlet 5001-3707
4 Cap (pack of 4) 5062-2485
&
(
)
'
