20
Installing the G1330B
Thermostat
Site Requirements
A suitable site environment is important to ensure optimum performance of
the thermostatted autosamplers.
Power Consideration
The thermostatted autosamplers comprises two modules, the autosampler
module (G1329A, G1389A, G1367A, or G2260A) and the thermostat module
(G1330B Therm). Both modules have a separate power supply and a power
plug for the line connections. The two modules are connected by a control
cable and both are turned on by the autosampler module.
The thermostatted autosampler power supplies have automatic voltage
selectors (see Table 1). Consequently there are no voltage selectors in the
rear of the two thermostatted autosampler modules. The autosampler
module has no externally accessible fuses, because automatic electronic
fuses are implemented in its power supply. The ALS thermostat power supply
has two externally accessible fuses.
WARNING To disconnect the thermostatted autosampler from line power, unplug
the power cord from the autosampler and the thermostat. The power
supplies still use some power, even if the power switch on the front
panel is turned off. Please make sure that it is always possible to
access the power plug.
WARNING Shock hazard or damage of your instrumentation can result if the
devices are connected to a line voltage higher than specified.
Power Cords
Your thermostatted autosampler modules are delivered with power cords
which match the wall socket of your particular country or region. The plug
