Repairing the ALS Thermostat Module
Removing the Top Cover and Foam
Removing the Top Cover and Foam
WARNING Do not disconnect or reconnect the autosampler to ALS thermostat
cable when the power cords are connected to either of the two
modules. This will damage the electronics of the modules.
Tools required Screwdriver Pozidriv #1
Preparations for this
procedure
Switch off ALS at the main power switch. Disconnect ALS and ALS thermostat power cords.
Remove ALS to ALS thermostat cable, and remove thermostat from stack.
1 Remove the front cover by pressing the both
clip fasteners on both sides of the cover.
2 Move the lever towards the power socket.
Lever
