Installing the G1330B Thermostat
Optimizing the Stack Configuration
Optimizing the Stack Configuration
If your thermostatted autosampler is part of a system, you can ensure
optimum performance by installing the thermostatted autosampler in the
stack in the position shown in Figure 6 and Figure 7. This configuration
optimizes the system flow path, ensuring minimum delay volume.
Figure 6 Recommended Stack Configuration (Front View)
Autosampler
Degasser
Thermostat
Column
Compartment
Detector
Control Module
Pump
Solvent Cabinet
