22
Installing the G1330B Thermostat
Site Requirements
WARNING Using the thermostatted autosampler at environmental temperatures
higher than 50 °C (122 °F) may cause the rear panel to become hot.
Table 1 Physical Specifications - Thermostatted Autosampler
Type Specification Comments
Thermostat
Weight 20.7 kg (45.6 lbs)
Dimensions
(height × width × depth)
140 × 345 × 435 mm
(5.5 × 13.5 × 17 inches)
Line voltage
100 – 120 or 220 – 240 VAC,
± 10 %
Automatic selection
Line frequency
50 or 60 Hz,
± 5%
Power consumption Autosampler: 300 VA
ALS Thermostat: 260 VA
Maximum
Maximum
Ambient operating temperature
4 – 40
°C (41 – 131 °F)
see WARNING on page 22
Ambient non-operating temperature
-40 – 70
°C (-4 – 158 °F)
Humidity
< 95 %, at 25 – 40
°C (77 – 104 °F)
Non-condensing;
Operating Altitude Up to 2000 m (6500 ft)
Non-operating altitude Up to 4600 m (14950 ft) For storing the
thermostatted
autosampler
Safety standards: IEC, CSA, UL, EN Installation Category II, Pollution Degree 2
