Repairing the ALS Thermostat Module
Exchanging the TCA board
3 By carefully pulling back on the upper part of
the TCA board unsnatch it from the holder.
4 Remove the TCA board.
5 Reinsert the new TCA board. 6 Gently push forward on the upper part of the
board, until it snatches into place.
