Overview
1
Overview
This section reviews the procedure for installing a nitrogen-phosphorus
detector (NPD) on an Agilent 6890 Gas Chromatograph (hereafter referred
to as the GC.) Before following this procedure, refer to the safety
information on the inside back cover.
Parts List
EPC
• NPD assembly: capillary optimized or adaptable
• Top and bottom insulation
• Nutwarmer cup and insulation (for adaptable NPD only)
NonEPC
• NPD assembly: capillary optimized or adaptable
• Top and bottom insulation
• Nutwarmer cup and insulation (for adaptable NPD only)
• Makeup gas regulator
• Two machine screws
Required Tools
• Electrostatic protection such as a grounded wrist strap (part no.
9300-0969, large or part no. 9300-0970, small)
• T-20 Torx screwdriver
• Diagonal cutters
• 7/16-inch wrench (nonEPC detectors only)
