Technical Information
Rear Panel
17
TwisTorr 74 FS AG On-board Cont
roller User Manual / 87-901-054-01 149/192
Figure 4 TwisTorr 74 FS AG On-board Controller Panel – X3509-64030
1
Remote I/O Connector (mating connectors supplied to start the pump with no
additional connections)
2
Remote Serial Connector for RS-232 and RS-485
3
Power output connector (24Vdc for Vent)
4
Power output connector (24Vdc for Gauge)
5
Power Mains socket
4
5
3
1
2
