Technical Information
Windows Protocol
174/192 TwisTorr 74 FS AG On-board Controller User Manual / 87-901-054-01
NOTE
Agilent cannot guarantee compliance with ECC regulations on radiated
emissions unless all external wiring is shielded, with the shield terminated on
the metal enclosure on the D-subconnector. The cable should be secured to the
connector with screws.
Serial Communication Descriptions
This unit can communicate using the “Windows” protocol. It can be
used as well with 232 or 485 media.
Windows Protocol
Description
Communication Format
8 data bit
no parity
1 stop bit
baud rate: 600/1200/2400/4800/9600 programmable
