Power Connection

TwisTorr 74 FS AG On-board Cont

roller User Manual / 87-901-054-01 155/192

Power Connection

Input Power Connector (24 Vdc type) X3509-64021

The following figure shows the input power connector.

Figure 7 Mains 24V

Input Power Connector X3509-64030

The following figure shows the input power connector.

Figure 8

GND EARTH

COMMON

+24VDC
