Charging the Battery
A new rechargeable battery comes in a discharged condition and must be
charged before use (refer to the
U1602B and U1604B User's and Service Guide
for charging instructions). Upon initial use (or after a prolonged storage
period) the rechargeable battery may require three to four charge/discharge
cycles before achieving maximum capacity. To discharge, simply run the
oscilloscope using the rechargeable battery’s power until it shuts down or
until the low battery warning appears.
Performance Characteristics
Performance Characteristic U1602B U1604B
Bandwidth 20 MHz
40 MHz
Maximum Real Time Sample
Rate
200 MSa/s
Channels 2
Maximum recording length 125,000 points, viewable on screen with zoom function
Display 4.5” color LCD
Vertical resolution 8 bits
Vertical sensitivity 5 mV/div to 100 V/div (1:1 scope probe)
50 mV/div to 1 kV/div (10:1 scope probe)
500 mV/div to 10 kV/div (100:1 scope probe)
Vertical zoom Vertical expand
Time base range 50 ns/div to 50 s/div 10 ns/div to 50 s/div
Input coupling DC,AC, Ground
True RMS Multimeter 6000 resolution counts for multimeter functions:
• Volt Meter: VDC, VAC and VDC+VAC measurement
• Ohm meter: Resistance, Diode Test, Continuity and Capacitance measurement
• Auxiliary meter: Temperature and Ampere measurement
FFT Not Available Rectangular, Hanning, Hamming, Black-
Harris
Dual Waveform Math CH1+CH2, CH1-CH2, CH2-CH1
Acquisition modes Normal, Average, Peak
