This section mainly introduces the basic operation and use of TRACER MINI platform, and how to
carry out secondary development of car body through external CAN port and CAN bus protocol.
3.1useandoperation
Check
Check the car body status. Check whether the car body is obviously abnormal; If yes, please
contact after-sales support;
Bootup
Click the button switch (Q3 in the electrical panel), under normal circumstances, the voltmeter is
The battery voltage is often displayed, and the headlight is on normally;
Disableoperation
Click the button switch to cut off the power supply;
Basicoperationprocessofremotecontrol
After the machine chassis is moved by the normal start TRACER MINI, start the remote
controller and select the control mode as the remote control mode, then the movement of the
TRACER MINI platform can be controlled by the remote controller.
3.2Charging
TRACER MINI product is equipped with a 10A charger by default, which can meet the charging
needs of customers.
Please. The specific charging procedure is as follows:
Make sure that the TRACER MINI chassis is in the shutdown state. Before charging, please
make sure that Q3 (button switch) in the rear electrical control panel is in the off state;
Insert the plug of the charger into the Q4 charging interface in the electric control panel of the
rear of the car;
Connect the charger to the power supply and turn on the charger switch to enter the charging
state.
When charging normally, there is no indicator light on the chassis. For more information, see the
charger indicator light.
3.3Development
TRACER MINI product provides a CAN interface for user development. Users CAN choose one of
the interfaces to control the car body.
●
●
●
●
●
●
●
●
●
