GENERAL INFORMATION
The GradeLight pipe laser provides alignment and grade for installation of gravity flow
sanitary and storm sewer pipelines, as well as for pipe jacking and tunneling.
The GradeLight includes:
· Infrared remote control
· Adjustable leg set for multiple pipe sizes
· Rechargeable Li-Ion battery pack and spare alkaline battery compartment
· OPTIONAL: Remote Receiver
Other features include a wide automatic self-leveling range, short length to fit tight inverts,
and adjustable target with magnetic base (included in designated packages).
Specifications
GradeLight 3000
Self-Leveling Range
+45% to -15%
Grade Range
+40% to -10%
Grade Entry
Rolling counter or digit select
Grade Display
0.001%
Azimuth Range
20 ft. at 100 ft. (6m at 30m)
Accuracy
± 1/16” at 100 ft.
(± 5mm at 100m; ± 10 arc sec.; ± .005% )
Cross Axis Leveling
Automatic leveling ± 6 degrees
Beam Type/Output
Visible laser diode, 635nm, < 5mW, Class 3R
Environmental
IP68; nitrogen purged
Power Supply
1) Rechargeable lithium ion battery pack
2) 110/230V converter (charge and run simultaneously)
3) Spare battery compartment for 4 D-cell alkaline batteries
4) Optional 12V power cord
Battery Life
40 hrs. Li-ion battery; 50 hrs. alkaline
Charging Time
5 hrs. maximum
Mounting
5/8 x 11 (female mounting thread)
Operating Temperature
-4° to 122° F (-20° to +50° C)
Storage Temperature
-40° to 140° F (-40° to +60° C)
Dimensions
Diameter: 5.5” (140 cm) / Length:<10.5“ (265mm)
Weight
7.6 lbs (3.5 kg) with alkaline battery
Warranty
1 year (2 and 3 Year Optional Warranties Available)
Remote
Operating Range
600’ (190m) front (through the pipe); 25’ (7.6m) from rear
Batteries
3 AA alkaline
Battery Life
2,000 hrs (1 year)
Dimensions
4.7” x 2.35” x 1.2” (119 x 60 x 30mm)
