8
Meadow mower agria 5300
Unpacking and assembly instructions
Unpacking
Open the top lid of the
cardboard box. Cut the
cardboard box at all four edges, and fold down
the cardboard walls.
Pa
ckaging should be recycled in an environmen-
tally friendly manner.
Assembly
Fold up the handlebar
• Unscrew and remove hexagon head screw (3) and hexagon nut (4)
• Swing up the steering bar (2). Insert the hexagon head screw (3) through the
bores. Install and tighten the hexagon nut (4).
Pull the hand lever for wheel switching (6) to position "0" and let it engage. The
wheel drive is now switched off and the machine can be moved without motor drive.
Pull the machine rearwards out of the cardboard box
Attach the cutter bar (5). See page 25
Carry out the steps for initial startup. See page 27.
