AI-Tek Instruments TACHTROL 3 User Manual

C. Use chart below to select the location of the decimal.
D. Push and hold Pb until the number from the chart appears in the first Display digit.
DECIMAL LOCATOR IS
:
0= No decimal
1= 1888.8 = 5
Fixed 2 = 188.88 = 6 Auto Range
Decimal 3 = 18.888 = 7 (right only)
C12
Analog Output
1. Zero Scale Constant
A. Turn CTW to 6.
B. Enter the constant by using DTW and Pb in the same manner as you did for C1 thru C5.
2. Full Scale Constant
A. Turn CTW to 7.
B. Enter constant by using the DTW and Pb in the same manner as you did for C1 thru C6.
3. Zero Scale Current
A. Turn CTW to 12.
B. Turn DTW to 5.
C. Select the zero scale current from chart (0 or 4ma).
D. Push and hold Pb until the number representing the zero you’ve selected appears in the
fifth Display digit.
ANALOG OUTPUT IS: . . . . . 4 - 20ma = blank
C
12
OR . . . . . 0 - 20ma = 1
Setpoint 1 Output
1. Setpoint Constant
A. Turn CTW to 8.
B. Enter constant by using DTW and Pb in the same manner as you did for C1 thru C7.
2. Hysteresis For Setpoint 1
A. Turn CTW to 10.
B. Enter the value of the hysteresis (given in percents) as a two digit number. (i.e. 5% as 05).
16
