INTERFACES (MX100TP only)
Full digital remote control facilities are available through the USB, RS232, LAN and GPIB interfaces.
Setting and readback resolutions are the same as for the Output and Meter specifications
respectively.
RS232:
Standard 9-pin D-connector. Baud rate 9600.
USB:
Standard USB 2.0 hardware connection.
LAN:
Ethernet 100/10base-T hardware connection. 1.4 LXI Core 2011.
GPIB:
Conforms with IEEE488.1 and IEEE488.2.
Remote Command
Processing Time:
Typically 120ms (80ms min, 160ms max) between receiving the
command terminator for a step voltage change at the instrument and
the output voltage beginning to change.
GENERAL
AC Input:
115V – 240V AC ± 10%, 50/60Hz.
Installation Category II.
Power Consumption:
500VA max.
Operating Range:
+5ºC to +40ºC, 20% to 80% RH.
Storage Range:
−40ºC to + 70ºC.
Environmental:
Indoor use at altitudes up to 2000m, Pollution Degree 2.
Safety & EMC:
Complies with EN61010-1 & EN61326-1.
For details, request the EU Declaration of Conformity for this
instrument via
http://www.aimtti.com/support (serial no. needed).
Size:
210 x 130 x 375mm (WxHxD) half rack width x 3U height.
Weight:
4.9kg
Options:
19-inch rack kit for one or two units.
