Aiphone IX-DVF Web Setting Manual

108
Configuring the Station
How to configure Daily Schedule
Configure the time at which relay output will be performed, in units of one day. A schedule one year from the set day
can be configured. 12 schedules can be set for each day.
1. Select the day for which to set a schedule from "Calendar."
2. Configure the "Start Time" and "End Time," and then click [Add].
3. When done, click [Update].
■ Start Time
Description Set the time when contact output starts.
Settings 00:00 - 23:59
Default values -
Calendar
Set schedule list

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
