Aiphone IX-DVF Web Setting Manual

107
Configuring the Station
1. Configure the "Start Time" and "End Time" for each day of the week.
2. When done, click [Update].
■ Start Time
■ End Time
How to delete the Weekly Schedule
1. Return settings to their default values, and then click [Update].
Description Set the time when contact output starts.
Settings 00:00 - 23:59
Default values -
Description Configure the time to stop relay output. If this is set earlier than “Start Time (→page 107)”, the
end time will be for the following day.
Settings 00:00 - 23:59
Default values -

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
